Product Details

With long, narrow detection areas that extend from both its sides, the battery-powered BX-80NR is specifically designed to be wirelessly wall-mounted centrally on a building. This unique detection pattern covers the building perimeter with a multi-layered, horizontal barrier that detects intruders before they break in. Included on the unit is a backbox that accepts most manufacturers wireless systems, making the BX-80NR a versatile, stable outdoor PIR requiring no running wire. To help reduce false activations, the range can be adjusted so that detection extends only to the end of the building. The unit also has a size-judging function, which helps it discriminate between large and small objects within the detection area.

Aninal tolerant and very stableThe convenience of "wireless"
The BX series is very stable to use in outdoor environment with small animal around. The sensor sends infrared beams on each side, both the top and bottom of the sensor. The beams need to detect a presence to trigger so a bird or a cat sitting on the window seal will not set the alarm off. Additionally, the BX-80 has extra features such as double conductive shielding, advanced temperature compensation and size judging function to provide reliable and stable detection.The BX-80R doesn't require any cable or wire at all to be installed. The low-current sensor is powered by batteries (not provided) which can last up to 3 years and has a backbox big enough to accommodate most wireless transmitters available on the market. The BX-80NR can be easily added onto a wireless alarm panel and extend the protection of the house or building to the outside.

OPTEX National Defense Authorization Act Declaration


  • Buildings
  • House
  • Garage

Key Features

  • Battery operated (battery not included)
  • Compatible with numerous wireless transmitters
  • Battery saving circuit
  • Variable detection range from 6 to 40ft on each side


No, BX-80NR does not include a communication transmitter even though it is compatible with most of the brands. BX-80NR has a rear compartment where to hold a wireless transmitter.

The BX80NR is a wireless device which is powered by 3-9V CC batteries.
