The Optex OA-Axis series is the new automatic door standard for use on sliding doors based on active infrared technique. The OA-Axis series is developed as a combination sensor for threshold safety and activation. The OA-Axis T is in compliance with the latest European and local regulations as EN 16005 and DIN 18650, tested and approved by the German test organisation TÜV. Due to its variety in output options the OA-Axis series meets the requirements in various markets.
The Optex OA-Axis series is the world first door sensor based on only active infrared technique, combining activation and safety into one sensor. By using the unique Optex presence detection technique the OA-Axis series provides maximum safety, around the threshold and offers at the same time a large motion detection area for the door activation.
The active infrared presence detection of the OA-Axis series can be set very accurately and can be moved 6° towards or away from the door. The installation of safety beams is no longer mandatory. The sensor detects a person or object and holds the door open as long as they are in or near the threshold area, even if they stop or pause. The Optex OA-Axis T is tested and approved by the German test organization TÜV and in compliance with the German DIN 18650 and the European Norm EN 16005.
The large detection area provides fast detection for any traffic, including trolleys, approaching from any angle. The sensor’s enhanced pattern depth enables it to detect people and objects farther away and allows the door to open conveniently for them. The presence and motion detection area’s can be adjusted independently.
By offering different types of output contacts the OA-Axis series meets the requirements and local standards in many different markets.
OA-Axis I: 1 relay output for activation and safety
OA-Axis II: 1 relay for safety and a second relay for motion/activation
OA-Axis T: 1 relay for motion and activation and an Opto coupler (NPN) in/output for safety
Easy adjustment: Installation time can be reduced to a minimum by using easily set switches and shutters, therefor the sensor can be quickly adjusted for many different applications. To adjust the presence detection area the use of an Optex Infrared finder is recommended.
Optex automatic door sensors guarantee premium performance and include a 3-year full replacement warranty.
Functionality Activation Safety
Opening Size Small Medium Large
