Product Details

The CX-702 is designed to give extremely stable long-range detection performance in a variety of internal commercial and industrial applications. With patented Multi-Focus technology, sensitivity is maintained through the entire coverage area, even in high temperature areas or in applications with low temperature contrast. Combined with Double Conductive Shielding and Temperature Compensation, a high level of false alarm protection is guaranteed. In addition, a unique feature to the CX-702 is the ability to choose between a 70' x 70' pattern and a 150' x 8' with a simple flip of the lens.

Features:
  • Multi-Focus Optics (Patent Listed)
  • Double Conductive Shielding (Patent Listed)
  • Completely Sealed Optics with Dual Structure
  • Dual Purpose Lens
  • Temperature Compensation Circuit
  • False Alarm Protection (RFI and Temperature Protection)
  • Disturbance-Free Tamper Switch
  • Easy Installation

Applications

  • Buildings
  • Roof / Ceiling

Key Features

  • 70 x 70' or 150 x 8' Indoor PIR
  • Multi-Focus Optics (Patent Listed)
  • Double Conductive Shielding (Patent Listed)
  • Completely Sealed Optics with Dual Structure
