Product Details

AX-100TF Range
AX-100TF Range

The AX-100TF short range photoelectric detector is compact in design with selectable beam frequencies. The selectable beam frequencies can be used to avoid unwanted crosstalk that can occur when using multiple photobeams over long distances or for beam stacking applications. The AX-100TF also carries the IP65 high durable structure, which prevents water, dust or bugs from getting into the unit. The ideal optical pitch design reduces false alarms due to accidental beam interruption by falling leaves, birds, and so on. These features deliver performance with higher reliability in severe outdoor environmental condition.

Replacment Lens (Covers) Optex part number is AX-TN/TFCOVER. (Sold Individually)

  • Selectable 4 channel beam frequencies
  • 4 step alarm indicator LED
  • Environmental disqualification circuit
  • IP65 structure
  • Lightning and surge protection
  • Anti-frost hood cover
  • 99% beam blocking stability
  • A.G.C circuit
  • Adjustable beam interruption time

OPTEX National Defense Authorization Act Declaration


  • Buildings
  • Perimeter

Key Features

  • 100' Outdoor 4 Channel Select Dual Beam
  • 4 step alarm indicator LED
  • Environmental disqualification circuit
  • Lightening and surge protection
